DESCRIPTION
|
PVC RESIN SG5
|
PRODUCTION DATE
|
APR.10,2021
|
|
TYPE
|
|
INSPECTION DATE
|
APR.10,2021
|
|
BATCH NO.
|
INTEGRATED SAMPLE
|
PERIOD OF VALIDITY
|
TWO YEARS
|
|
EXECUTION
STANDARD
|
GB.T5761-2006 GB/T4803-94
|
|
ITEM
|
INDEX VALUE
|
TEST RESULT
|
SINGLE JUDGEMENT
|
|
K VALUE
|
66-68
|
67
|
PASS
|
|
VISCOSITY NUMBER ml/g
|
118-107
|
113
|
PASS
|
|
NUMBER OF IMPURITY PARTICLE/
900cm2
|
Max 30
|
16
|
PASS
|
|
APPEARANCE DENSITY g/ml
|
Min0.45
|
0.54
|
PASS
|
|
RESIDUAL AFTER SIEVE
|
0.250mm %
|
Max2
|
0.4
|
PASS
|
|
0.063mm %
|
MAX 90
|
—
|
----------
|
|
NUMBER OF GRAIN /400cm2
|
Max40
|
19
|
PASS
|
|
VOLATILE MATTER AND MOISTURE
CONTENT %
|
Max 0.4
|
0.10
|
PASS
|
|
RESIDUAL CHLORE THYLENE CONTENT
mg/kg
|
Max 10
|
1
|
PASS
|
|
THERMO STABILITY(WHITENESS
DEGREE 160℃ 10min) %
|
Min 75
|
85
|
PASS
|
|
PLASTICIZER ABSORBENCY VALUE OF 100g PVC %
|
Min 17
|
22
|
PASS
|
|
THE RESULT OF INSPECTION PROVES THAT THE QUALITY OF PRODUCTION IS IN CONFORMITY WITH THE SUPERIOR CLASS REQUEST OF ABOVE STANDARD.
|
|
|
|
